Feature:
Materials of body: Brass / Nickel-Plated.
Working Temperature: -20℃~+80℃
◆ Applicable medium :Compressed air, gas,vacuum.
◆ Thread type: NPT, BSPT(PT or R), BSP, Metric.
◆ Recommended tubings: PA11,PA12,PA6, Polyethylene PE,Polyurethane PU(98 Shore A).
◆ Acceptable Tolerance of tubing: ±0.1mm.
◆ Working Pressure range: 0~20Bar.
BSC Male speed control valve
BPV Elbow union
BPOC Male round straight
KQ series black push-in tube fittings
KJ series mini type push-in fittings
ASN2 series throttle valve(with air muffler)
FPB-S Ferrule-type Compression Male Tee Branch
RPL-G-S Rapid Screw Rotatable 90° Elbow With O Ring
RPL-SF Series Rapid Screw 90° Elbow
