Magnetic distance sensor

Magnetic distance sensor is also called magnetron. It is similar to Hall element, but the principle and nature are different. It is a switching element controlled by magnetic field signal. It has no magnetic disconnection and can be used to detect the state of circuit or mechanical movement.

Magnetic sensor is used to detect the position of the cylinder piston, that is, to detect the movement stroke of the piston. It can be divided into two types: contact type (reed tube type with contact) and contactless type (transistor type without contact). Common mag sensors are: CS1-M, CS1-MP, CS1-MN Magnetic sensor for DNC standard cylinder, CS1-J, CS1-JP, CS1-JN Magnetic sensor for SDA compact cylinder.

Magnetic field sensor is mainly used to control the action of industrial machinery, the range of rotation ratio is 1:1 to 1:150; the overall size is suitable for assembly in a small space, the transmission shaft and the gear drive shaft are made of stainless steel material, the gear and drive The bushing is made of self-lubricating thermoplastic material, various materials and components have good wear resistance, and the equipment has good waterproof and dustproof performance.
